| SPECIFICATION | SDJ-1200 |
| Max.Stroke of X Axis: | 1200mm |
| Max.Stroke of Y Axis | 1100mm |
| Max.Stroke of Z Axis | 220mm |
| Cutter Head Axis Distance | 200mm |
| Main Axis Speed | 18000r/min |
| Main Axis Motor | 2.2kw*2 |
| Servo Motor | 1.0kw*3 |
| Installation Motor Power | 10HP |
| Dia. Of Dust Suction | Dia.:100mm*2pcs |
| Overall Dimension | 2200*2000*1900mm |
