1.Conveyor chain blocks and guide rails made by special materials with specific craftsmanship. Automatic lubrication, high precision and long service life.
2.Lifting feeding table easy for frequent height adjustment, reduce labor intensity and improve processing efficiency.
3.Variable feeding speed adjustment device, suitable for ripping all kinds of wood.
4.Patented unique feeding splitter, suitable for ripping alf kinds of wood.Patented tooth design on side of the conveyor chain block. Cut off the jammed wood pieces beside saw blade, minimized probability of getting stuck with the saw blade.
5.Effectively reduce or avoid injuries.
| SPECIFICATION AND MODEL | ICW-MJ153 |
| Max. Saw blade diameter (mm) | Φ 305 |
| Max. working thickness (mm) | 85 |
| Cutting width (mm) | 360 |
| Main spindle revolution (r/min) | 3300 |
| Spindle diameter (mm) | Φ 50.8 |
| Feeding speed (m/min) | 12月22日 |
| Feeding motor power (kw) | 0.75 |
| Main motor power (kg) | 7.5 |
| Lubricate pump motor power (w) | 20 |
| Total power (kw) | 8.6 |
| Working tabie sizer (mm) | 1550x715 |
| Dimension (mm) | 1750x945x1400 |
| Net weight (kg) | 920 |
