| TECHNICAL SPECIFICATION | SMF-515BT | SMF-515B | SMF-515BT45 |
| Edging Thickness | 0.4-3mm | 0.4-3mm | 0.4-3mm |
| Edging Width | 12-45mm | 12-45mm | 12-45mm |
| Working Thickness | 10-40mm | 10-40mm | 10-40mm |
| Heating Power | 1.8kW | 1.8kW | 1.8kW |
| Conveyor Motor Power | 0.2kW (stepless speed regulation) | 0.2kW (stepless speed regulation) | 0.2kW (stepless speed regulation) |
| Feeding Speed | 1-18m/min | 1-18m/min | 1-18m/min |
| Air Pressure | 0.4-0.5Mpa | 0.4-0.5Mpa | 0.4-0.5Mpa |
| Total Power | 2.0kW | 2.0kW | 2.0kW |
| Overall dimensions(L*W*H)mm | 1000×830×1000 | 950×750×1000 | 1110×830×1000 |
| Packing Dimension(L*W*H)mm | 1050*890*1110 | 1050*830*1110 | 1150*880*1110 |
| Net weight (KG) | 160kg | 152kg | 175kg |
| Weight of Packing Box (multi layer veneer) | 50kg | 48kg | 55kg |
| Total weight of Packing | 210kg | 200kg | 230kg |
| Edging Shapes | straight, curved | straight, curved | straight, curved |
| Min.Diameter of Arcs | 20mm | 20mm | 20mm |
